Description

The D38999/26WA35SA Circular Connector Plug is a high-reliability electrical connector designed for demanding aerospace, aviation, military, marine, and industrial applications. Belonging to the MIL-DTL-38999 Series III connector family, this connector features a straight plug design, six female socket contacts, and a durable aluminum shell with an olive drab cadmium finish.

The connector uses gold-plated mating contacts and crimp termination to support dependable electrical connections in compatible cable assemblies and equipment. Its threaded coupling mechanism provides secure mating with a compatible connector receptacle, making it suitable for applications requiring robust electrical interconnections.

Key Features and Benefits

• MIL-DTL-38999 Series III: Designed for demanding electrical interconnection applications.
• Six Socket Contacts: Provides six female contacts in the 9-35 insert arrangement.
• Olive Drab Cadmium Finish: Features a protective finish on the aluminum shell.
• Gold-Plated Contacts: Supports reliable electrical contact performance.
• Crimp Termination: Suitable for compatible crimp-contact cable assemblies.
• Threaded Coupling: Helps provide secure mating with compatible connectors.
• Straight Plug Configuration: Suitable for free-hanging cable installations.
• Rugged Metal Construction: Designed for demanding operating environments.

Technical Specifications

• Part Number: D38999/26WA35SA
• Connector Type: Circular electrical plug
• Connector Series: MIL-DTL-38999 Series III
• Contact Arrangement: 9-35
• Number of Contacts: 6
• Contact Type: Female socket
• Shell Material: Aluminum alloy
• Shell Finish: Olive drab cadmium
• Contact Finish: Gold
• Termination Method: Crimp
• Coupling Mechanism: Threaded
• Mounting Style: Free-hanging / cable
• Keying Position: A
• Typical Operating Temperature: -65°C to +175°C, depending on manufacturer and exact configuration

Applications

The D38999/26WA35SA connector is suitable for compatible applications in:

• Aerospace and aviation electrical systems
• Military and defense equipment
• Aircraft instrumentation and avionics
• Marine electrical systems
• Industrial control equipment
• Communications systems
• High-reliability cable assemblies
